USB Type-C one cable, 10.1″ WUXGA Industrial Monitor with P-CAP Touch Control, Direct HDMI, DP

€ 0,00

In IIoT and Industry 4.0, customers need data visualization for process management. The FPM-710SW is a sleek, industrial-grade touchscreen monitor.

Out of stock

SKU: FPM-710SW Categories: , Brand:

Description

In IIoT and Industry 4.0, more and more customers need data to be visualized to help process management and decision making. The FPM-710SW are industrial-grade,widescreen monitor with sleek, simple lines and a true-flat touchscreen. Equipped with P-CAP multi-touch control and an IP66-rated front bezel,FPM-710SW series is specifically designed for industrial applications. FPM-710SW is first use type-C one single cable Ind. Touch Monitor. Moreover, FPM-710SW support various mount options to make these monitors ideal for factory and machine automation display applications.

Features:
USB Type-C connection touch monitor 1920 x 1200
10.1″ WUXGA TFT LED LCD with true-flat touchscreen
16:10 wide screen aspect ratio, increases viewing area by 40%
Supports multi-touch control via USB interface in Windows 7/8/10 OS
Slim design enables easy installation with Build-in panel mount kit
Supports various mount options: panel, desktop, and VESA arm
Touchscreen with reliable glass surface and P-CAP touch control
Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
Lockable I/O connectors
Supports various mount options: panel, desktop, and VESA mounting
First single cable Ind. Touch Monitor

Attachments

Product features

  • Model: Monitor
  • ETIM Code: EC004862
  • ETIM Class: Monitor
  • Type of display: TFT
  • Resolution: Other
  • Housing colour: Black
  • With display backlight: Yes
  • Colour display: Yes
  • Number of colours of the display: 16700000
  • Visible diagonal screen size (inch): 10.1 Inch
  • Number of pixels, horizontal: 1920
  • Number of pixels, vertical: 1200
  • Image format: 16:10
  • With on-screen keyboard: No
  • With touch screen: Yes
  • Mouse-cursor control integrated: No
  • Supply voltage DC: 12 - 24 Volt
  • Voltage type (supply voltage): DC
  • Number of HDMI connections: 1
  • Number of inputs DisplayPort (DP): 1
  • VGA-connection (D-Sub 15-pole): No
  • Number of ports USB-A: 1
  • Number of ports USB-C: 1
  • With HW-interface PS2: No
  • Operating temperature: -10 - 50 Degrees celsius
  • Freestanding: No
  • Suitable for rail mounting: No
  • Wall mounting/direct mounting: Yes
  • Front built-in possible: Yes
  • Rack-assembly possible: No
  • Mounting Interface Standard (MIS) according to VESA: 100x100
  • Suitable for safety functions: No
  • Degree of protection (IP): IP66
  • Width: 261 mm
  • Height: 180 mm
  • Depth: 45 mm
  • Variant: Industrial
  • Weight: 1.1 kg

Description

In IIoT and Industry 4.0, more and more customers need data to be visualized to help process management and decision making. The FPM-710SW are industrial-grade,widescreen monitor with sleek, simple lines and a true-flat touchscreen. Equipped with P-CAP multi-touch control and an IP66-rated front bezel,FPM-710SW series is specifically designed for industrial applications. FPM-710SW is first use type-C one single cable Ind. Touch Monitor. Moreover, FPM-710SW support various mount options to make these monitors ideal for factory and machine automation display applications.

Features:
USB Type-C connection touch monitor 1920 x 1200
10.1″ WUXGA TFT LED LCD with true-flat touchscreen
16:10 wide screen aspect ratio, increases viewing area by 40%
Supports multi-touch control via USB interface in Windows 7/8/10 OS
Slim design enables easy installation with Build-in panel mount kit
Supports various mount options: panel, desktop, and VESA arm
Touchscreen with reliable glass surface and P-CAP touch control
Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
Lockable I/O connectors
Supports various mount options: panel, desktop, and VESA mounting
First single cable Ind. Touch Monitor

Attachments
