DC Axial Fan 120x120x38mm, 24Vdc

DC Axial Fan 120x120x38mm, 24Vdc

€ 0,00

DC Axial Fan 120x120x38mm, 24Vdc, 53 l/s (max); 9,75mm H2O (max)

Out of stock

SKU: 125DS2LP11000 A Categories: , Brand:

Description

Specifications:
• Weight: 0,33 Kg / 0,73 Lb
• Housing in plastic UL 94 V-0
• Impeller in plastic UL 94 V-0
• L-10 life expectancy at 40°C: 80.000 hours
• Operating temperature range: -40 / +70 °C except DX and DZ : -20 / +70 °C
• Storage temperature: -40 / +70°C
• Connection: Leads
• Brushless DC motor
• Integrated circuit
• IP20
Options:
• Speed sensor
• Alarm
• Other IP levels up to IP66
• Other voltages
• PWM in development
• Special construction : salt spray, dry cold, wet heat, schock, vibration. Contact us for more information

Attachments

Product features

  • Model: Axial fan
  • ETIM Code: EC010883
  • ETIM Class: Wall mounted fan (built-up)
  • Housing material: Plastic
  • Air volume, unloaded: 191 Cubic metre per hour
  • Max. air volume at 50 Pa: 108 Cubic metre per hour
  • Connection voltage: 24 Volt
  • Power consumption: 7.34 Watt
  • With thermal overload protection: No
  • Electrical connection: Cable
  • Degree of protection (IP): IP20
  • Max. air temperature: 70 Degrees celsius
  • Suitable for electronic control: No
  • Suitable for transformer control: No
  • Suitable for frequency control: No
  • Operation: Other
  • Timer: None
  • Hygrostat: None
  • Louver: None
  • With non-return valve: No
  • Height: 120 mm
  • Width: 120 mm
  • Depth: 38 mm
  • Impeller diameter: 105 Millimetre
  • Colour: Black
  • Variant: DC
  • Weight: 0.33 kg
