100mm Lid - Snap On - 2 Metres Long

100mm Lid – Snap On – 2 Metres Long

€ 0,00

• Cover (Part No: TC1279‐24SN), snaps onto 100mm duct (Part No: TC 1279‐23);

1 in stock

SKU: TC1279-24SN-B Categories: , ,

Description

The 100 mm duct lid (Part No: TC1279‐24SN) is a snap fit onto 100mm straight duct (Part No: TC1279‐23). The lid is quickly and easily fitted and removed from 100mm straight duct, when required. Both the lid and duct are made of tough Noryl plastic with a non ‐ halogen fire retardent.

Product features

  • ETIM Code: EC000047
  • ETIM Class: Cable tray
  • Height: 15 mm
  • Width: 115 mm
  • Material thickness: 3 Millimetre
  • Length: 2000 Millimetre
  • Working length: 2000 Millimetre
  • Side perforation: No
  • Bottom perforation: No
  • NATO-mounting holes: No
  • Model: Straight duct length
  • Type of connection: Click in mounting
  • Suitable for circuit integrity: No
  • Material: Plastic
  • Material quality: Other
  • Surface protection: Untreated
  • Colour: Black
  • RAL-number: 9005
  • Weight: 1.16 kg
  • Possible support spacing: 1 - 1.5 Metre
  • Safe working load according to IEC 61537 with support spacing 1.5 m: 350 Newton per metre
  • Variant: black
  • Depth: 2000 mm
  • Working temperature: -20 - 70 Degrees celsius

Description

The 100 mm duct lid (Part No: TC1279‐24SN) is a snap fit onto 100mm straight duct (Part No: TC1279‐23). The lid is quickly and easily fitted and removed from 100mm straight duct, when required. Both the lid and duct are made of tough Noryl plastic with a non ‐ halogen fire retardent.
