Elbow Assembly External Slot Down 90° 220mm Duct

 0,00

Provides optical fibre cord access and retrofit options
• Clips straight into a joiner
• Standard joiners (Part No: TC1279-25) or slotless joiners (TC 1279-250A);available separately
• Tough, fire retardant material
• Purchase by the unit

1 in stock

SKU: TC1279-123R-B Categories: , ,

Description

This 90° down elbow is a 220mm vertical drop off with an external slot, so that new optical fibre cords can be installed within the elbow, and existing optical fibre cords removed, where necessary. This is usually installed where optical fibre cords are to be dropped off below. There are two 220mm outlets, which use either: standard joiners (Part No: TC1279-25) or slotless joiners (TC 1279-250A); which are available separately.

Attachments

Product features

  • ETIM Code: EC002400
  • ETIM Class: Bend for cable tray
  • Change of direction: Vertically descending
  • Angle: 90°
  • Construction type: Bend rigid
  • Bend model: Smooth bend
  • For connection with screws: No
  • For screwless connection: Yes
  • With cover: Yes
  • Inner radius: 30 Millimetre
  • Suitable for cable tray height: 100 Millimetre
  • Suitable for cable tray width: 220 Millimetre
  • Material thickness: 3 Millimetre
  • Side perforation: No
  • Bottom perforation: No
  • NATO-mounting holes: No
  • Model: Elbows
  • Suitable for circuit integrity: No
  • Material: Plastic
  • Stainless steel, pickled: No
  • Colour: Black
  • RAL-number: 9005
  • Variant: black
  • Width: 175 mm
  • Height: 175 mm
  • Depth: 226 mm
  • Weight: 0.56 kg
  • Material quality: Other
  • Surface protection: Other
  • Working temperature: -20 - 70 Degrees celsius

Description

This 90° down elbow is a 220mm vertical drop off with an external slot, so that new optical fibre cords can be installed within the elbow, and existing optical fibre cords removed, where necessary. This is usually installed where optical fibre cords are to be dropped off below. There are two 220mm outlets, which use either: standard joiners (Part No: TC1279-25) or slotless joiners (TC 1279-250A); which are available separately.
