Name: Elbow 90° Up And Down 100mm Duct
SKU: TC1279-39A-B
Availability: InStock

Elbow 90° Up And Down 100mm Duct

€ 0,00

• Clips straight into joiner
• Tough, fire retardant material
• Joiners (Part No’s: TC1279-27, Telstra No: 035300514 or TC1279-248A), available separately
• Purchase by the unit

1 in stock

Home » Cable Management » YellowDuct® » Elbows » Elbow 90° Up And Down 100mm Duct

Description
Attachments

Description

The 100mm up/down elbow assembly is used to provide a vertical right – angled bend with standard 100mm straight ducting. It provides a simple method for directing fibres between different levels. It requires a standard joiner (Part No: TC1279-27, Telstra No: 035300514), or a slotless joiner (Part No: TC1279-248A) at each interface; which provides a smooth & strong joint.

Attachments

TC1279-39A (mh).pdf

Product features

ETIM Code: EC002400

ETIM Class: Bend for cable tray

Change of direction: Vertically rising

Angle: 90°

Construction type: Bend rigid

Bend model: Smooth bend

For connection with screws: No

For screwless connection: Yes

With cover: Yes

Inner radius: 30 Millimetre

Suitable for cable tray height: 100 Millimetre

Suitable for cable tray width: 100 Millimetre

Material thickness: 3 Millimetre

Side perforation: No

Bottom perforation: No

NATO-mounting holes: No

Model: Elbows

Suitable for circuit integrity: No

Material: Plastic

Stainless steel, pickled: No

Colour: Black

RAL-number: 9005

Variant: black

Width: 174 mm

Height: 106 mm

Depth: 174 mm

Weight: 0.29 kg

Material quality: Other

Surface protection: Other

Working temperature: -20 - 70 Degrees celsius
