Breakout Kit And Down Elbow

Breakout Kit And Down Elbow

€ 0,00

• Fits into the standard cut out in 220 & 100mm ducting
• Includes: ramp off (Part No: TC1279-42); break out adaptor assembly (Part No; TC1279-93A); joiner (Part No: TC1279-73); and a 90 degree up elbow (Part No: TC1279-143A).
• Fits directly to 50mm slotted (Part No’s: TC1279-81SLA or TC1279-81SLXA) or straight duct (Part No: TC1279-81XA); using a standard joiner.
• These items are available separately.
• Tough, fire retardant material
• No joiners are necessary.

1 in stock

SKU: TC1279-143KIT Categories: , ,

Description

The break out Kit is used to provide a safe open exit, for optical fibre cord, at any point in 220 & 100mm ducting, to 50mm duct, feeding in a vertical plane. It clips straight into a cut out provided by the cut out Tool (Part No: TC1279-50KIT), and provides a 90 degree up elbow, over which a 50mm slotted duct (Part No: TC1279-81SLA or TC1279-81SLXA) or straight duct (Part No: TC1279-81XA), can be fitted, using a 50mm standard joiner. A ramp off is also provided to maintain fibre bending radius, up to the break out.

Product features

  • ETIM Code: EC002400
  • ETIM Class: Bend for cable tray
  • Change of direction: Vertically descending
  • Angle: 90°
  • Construction type: Bend rigid
  • Bend model: Smooth bend
  • For connection with screws: No
  • For screwless connection: Yes
  • With cover: Yes
  • Inner radius: 30 Millimetre
  • Suitable for cable tray height: 50 Millimetre
  • Suitable for cable tray width: 50 Millimetre
  • Material thickness: 3 Millimetre
  • Side perforation: No
  • Bottom perforation: No
  • NATO-mounting holes: No
  • Model: Elbows
  • Suitable for circuit integrity: No
  • Material: Plastic
  • Stainless steel, pickled: No
  • Colour: Yellow
  • RAL-number: 1026
  • Width: 140 mm
  • Height: 70 mm
  • Depth: 210 mm
  • Weight: 0.133 kg
  • Material quality: Other
  • Surface protection: Other
  • Variant: yellow
  • Working temperature: -20 - 70 Degrees celsius

Description

The break out Kit is used to provide a safe open exit, for optical fibre cord, at any point in 220 & 100mm ducting, to 50mm duct, feeding in a vertical plane. It clips straight into a cut out provided by the cut out Tool (Part No: TC1279-50KIT), and provides a 90 degree up elbow, over which a 50mm slotted duct (Part No: TC1279-81SLA or TC1279-81SLXA) or straight duct (Part No: TC1279-81XA), can be fitted, using a 50mm standard joiner. A ramp off is also provided to maintain fibre bending radius, up to the break out.
