Breakout 100mm Down Elbow Kit

Breakout 100mm Down Elbow Kit

€ 0,00

• Provides easy access to optical fibre cords; which can also be retro fitted
• Can be used on prepared: 300mm; 220mm or 100mm x 100mm duct (Use Tool Part No: TC1279‐231KIT; available separately)
• Fits directly onto the side of either a prepared 300mm x 100mm; 220mm x 100mm or 100mm x 100mm duct
• Tough, fire retardant material
• Two 46mm dia outlet holes connect directly to 44mm/50mm OD flexible, convoluted tube (Part No: TC1279‐26, 1 metre long or TC1279‐53, 2 metres long); available separately.
• Two 46mm dia outlet holes connect directly to 44mm/50mm OD flexible, split, convoluted tube (Part No: TC1279‐350, 1 metre long); available separately.
• Purchase by the unit

1 in stock

SKU: TC1279-39KIT Categories: , ,

Description

This Kit enables a vertical break‐out with 2 x 44/50mm dia convoluted, flexible tubes at any point along a length of: 300mm; 220mm or 100mm duct, while maintaining fibre bend radii throughout. It consists of: a standard break‐out, a 90‐degree down elbow, a standard duct end and one joiner (Part No’s: TC1279‐218A, TC1279‐111A, TC1279‐57C & TC1279‐27). The 100 x 100mm vertical drop off comes with an external cover so that cords within the elbow are easily accessed. This Kit is usually installed where cords are to be dropped off below.

Product features

  • ETIM Code: EC002400
  • ETIM Class: Bend for cable tray
  • Change of direction: Vertically descending
  • Angle: 90°
  • Construction type: Bend rigid
  • Bend model: Smooth bend
  • For connection with screws: No
  • For screwless connection: Yes
  • With cover: Yes
  • Inner radius: 30 Millimetre
  • Suitable for cable tray height: 100 Millimetre
  • Suitable for cable tray width: 100 Millimetre
  • Material thickness: 3 Millimetre
  • Side perforation: No
  • Bottom perforation: No
  • NATO-mounting holes: No
  • Model: Elbows
  • Suitable for circuit integrity: No
  • Material: Plastic
  • Stainless steel, pickled: No
  • Colour: Yellow
  • RAL-number: 1026
  • Width: 100 mm
  • Height: 55 mm
  • Depth: 210 mm
  • Weight: 0.103 kg
  • Material quality: Other
  • Surface protection: Other
  • Variant: yellow
  • Working temperature: -20 - 70 Degrees celsius

Description

This Kit enables a vertical break‐out with 2 x 44/50mm dia convoluted, flexible tubes at any point along a length of: 300mm; 220mm or 100mm duct, while maintaining fibre bend radii throughout. It consists of: a standard break‐out, a 90‐degree down elbow, a standard duct end and one joiner (Part No’s: TC1279‐218A, TC1279‐111A, TC1279‐57C & TC1279‐27). The 100 x 100mm vertical drop off comes with an external cover so that cords within the elbow are easily accessed. This Kit is usually installed where cords are to be dropped off below.
