100mm 90° Down Elbow Assembly

 0,00

• Enables fibre access and retrofit options
• Clips straight into joiner
• Tough, fire retardant material
• Joiners, either: standard joiners (Part No. TC1279-27) or slotless joiners (Part No: TC1279-248A); available separately
• Purchase by the unit

1 in stock

SKU: TC1279-111R-B Categories: , ,

Description

The 90°, retrofit, down elbow is a 100mm vertical drop off with an external slot, so that new optical fibre cords can be installed within the elbow and existing optical fibre cords removed. This is usually used where optical fibre cords are to be dropped off below. There are two 100mm outlets, which use either: standard joiners (Part No: TC1279-27) or
slotless joiners (TC 1279-248A) which are available separately.

Attachments

Product features

  • ETIM Code: EC002400
  • ETIM Class: Bend for cable tray
  • Change of direction: Vertically descending
  • Angle: 90°
  • Construction type: Bend rigid
  • Bend model: Smooth bend
  • For connection with screws: No
  • For screwless connection: Yes
  • With cover: Yes
  • Inner radius: 30 Millimetre
  • Suitable for cable tray height: 100 Millimetre
  • Suitable for cable tray width: 100 Millimetre
  • Material thickness: 3 Millimetre
  • Side perforation: No
  • Bottom perforation: No
  • NATO-mounting holes: No
  • Model: Elbows
  • Suitable for circuit integrity: No
  • Material: Plastic
  • Stainless steel, pickled: No
  • Colour: Black
  • RAL-number: 9005
  • Variant: black
  • Width: 175 mm
  • Height: 175 mm
  • Depth: 106 mm
  • Weight: 0.3 kg
  • Material quality: Other
  • Surface protection: Other
  • Working temperature: -20 - 70 Degrees celsius

Description

The 90°, retrofit, down elbow is a 100mm vertical drop off with an external slot, so that new optical fibre cords can be installed within the elbow and existing optical fibre cords removed. This is usually used where optical fibre cords are to be dropped off below. There are two 100mm outlets, which use either: standard joiners (Part No: TC1279-27) or
slotless joiners (TC 1279-248A) which are available separately.
